The GW3323 Bluetooth smart wristband solution enables one chip to meet the dual requirements of "wireless connectivity" and "algorithm processing", helping to innovate product applications and enhance market competitiveness.

GW3323 Bluetooth Smart Wristband Solution

The solution supports low-power Bluetooth 5.2 and classic Bluetooth SPP communication protocols, which can achieve greater compatibility and interconnection with more Bluetooth devices. With a built-in high-performance 2.4GHz RF transceiver and 0.2A charging current, it has higher integration, stronger connectivity, and lower power consumption, which helps to reduce production costs, improve transmission performance, and expand application functions.

•  Adopt GW3323 dual-mode Bluetooth 5.2 wireless MCU

•  External high-precision 6-axis sensor, supports accurate pedometer, movement algorithm, and sedentary reminder

•  Support cell phone reminders and hands-up display

•  External AFE can collect heart rate and monitor sleep

•  Ultra-low power consumption supports 14 days long standby

•  SPI color display UI

Performance Advantages

•  Based on 32-bit high-performance RISC-V core

•  Operating frequency: 160 MHz; 1MB Flash, 256KB SRAM

•  Support OTA, DSP command, and TWS communication

•  Receive sensitivity is -94dBm under 2Mbit/s EDR, maximum transmit power reaches +9dBm

•  Support AAC, mSBC decoding

•  Built-in PMU with Charger/Buck/LDO

•  built-in full-speed USB 2.0 host and device controller

•  Integrated USART*3, SPI*2, I2C, PWM*9, SDIO and other communication peripherals
