The Body Control Module (BCM) is a cornerstone of automotive electronic control systems. It oversees a variety of vehicle electrical systems, such as lighting, windows, doors, seat adjustments, mirror controls, anti-theft alarms, remote control, and tire pressure monitoring. The BCM ensures the efficient operation of these systems, offering real-time feedback to enhance driving safety and comfort.

A typical body control system incorporates essential hardware, including an MCU, signal acquisition modules, communication modules, power modules, drivers, and sensors. As the progress of automotive electrification and intelligence continues, vehicle electronic architectures become increasingly complex and interactive. This trend drives BCMs to shift from distributed to centralized systems, integrating more features and functionalities.

G32A1445 BCM Solution

In response to industry demands, Geehy introduces the G32A1445-based BCM solution. This solution offers optimal cost-effectiveness and functional integration, addressing challenges in power efficiency, design complexity, compatibility, and safety. It supports centralized management while ensuring high-performance, intelligent, and stable system operations.

The G32A1445 BCM solution has reached mass production and has been deployed in vehicles. Utilizing the automotive-grade G32A1445 MCUs, this solution enables diverse communication modes and multiple control I/O functions. It efficiently processes sensor feedback to monitor vehicle status in real time, covering aspects such as window and door states, ECU temperature, and lighting control. An LPUART interface records data to EEPROM, while the 12V power system ensures signal conditioning, power protection, and SBC (System Basis Chip) operation. The communication circuitry integrates CAN/LIN buses for real-time feedback and seamless signal communication. The sensor module provides diagnostic and control data, facilitating the monitoring of overloads, overheating, and bulb failures.

Block Diagram of the G32A1445 BCM Solution

Features of the G32A1445 BCM Solution

· Provides large storage capacity to accommodate configuration parameters and fault codes.

· Enables advanced communication and control applications with rich peripherals.

· Delivers multi-channel data acquisition with high-frequency sampling capability.

· Ensures reliable interaction with the automotive CAN bus system by complying with 2.0A/2.0B (active) standards and supporting communication speeds up to 1 Mbit/s.

· Supports fault diagnostics for CAN/LIN bus systems.

· Includes built-in short-circuit and overload protection.

Key Features of the Automotive G32A1445 MCUs

Geehy emphasizes innovation and quality, driving the automotive industry toward a smarter, safer, and greener future. With the G32A series MCUs, GURC ultrasonic sensing processors, and GALT matrix lighting control ICs, Geehy delivers robust, reliable, and efficient solutions for modern automotive challenges.
