Supply voltage operating range: 5.5–20V
Compatible with 3.3V/5V logic inputs
Floating offset voltage: +200V
Built-in dead time: 220ns
Built-in VCC/VBS undervoltage protection
Built-in shoot-through prevention
High dv/dt noise immunity
Matched high-side/low-side channel propagation delay
Built-in input/output bias resistor
Peak output source current: 2.0A@15 V; fall time: 20ns with 3.3nF load
Peak output sink current: 2.7A@15V; rise time: 35ns with 3.3nF load
Package
- TSSOP20
- QFN24
