Communication Interface
- 2 independent DSI3 interfaces compliant with the protocol standard: DSI3 Bus Standard (Revision 1.00, February 16, 2011)
Supported Connection Methods
- Point-to-Point
- Parallel Bus
- Daisy Chain Bus
Multiple Online Configuration Functions
- Supports up to 15 DSI3 slave nodes
- Supports up to 16 data packets per frame
- Supports modifying waveform smoothness to optimize EMC performance
Supported Operating Modes
- CRM: Command Response Mode
- PDCM: Periodic Data Collection Mode
- BDM: Background Diagnostic Mode
- DM: Slave Address Allocation Mode
Application
- Ultrasonic Parking Assistance System
- DSI3 Bus Network
Functional Safety
- AEC-Q100 Grade 2
- Compliant with ISO 26262 Functional Safety Level ASIL-B
